Industrial Sectional Overhead Door for Airport Cargo Buildings
Airport cargo buildings handle large volumes of freight, requiring doors that support high-speed loading and unloading, frequent forklift and cargo vehicle traffic, and robust operational reliability. An Industrial Sectional Overhead Door offers a durable lift-up solution that enhances workflow efficiency, ensures security, and maximizes space utilization in airport cargo facilities.
Key Features for Airport Cargo Applications
Heavy-Duty Industrial Panels
Steel or aluminum panels resist impact and abrasion from daily cargo movement.
Reinforced Tracks & Balanced Spring System
Ensures smooth lifting and consistent operation during high-frequency use.
Sealing & Protection Performance
Minimizes air exchange and protects cargo from dust and external elements.
Why Sectional Overhead Doors Are Ideal for Airport Cargo Facilities
Vertical Lift Design for Efficient Dock Areas
Doors open upward, keeping loading zones clear for bulky cargo handling.
Reliable Performance Under Heavy Use
Designed for constant operation with minimal downtime.
Compatibility with Automated Systems
Supports integration with conveyor systems and material handling equipment.
Product Specifications
| Item |
Description |
| Material |
SUS 304 Stainless Steel,Aluminium Alloy,Color Coating Plate |
| Thickness of Panel Mateiral |
0.326 / 0.45mm / 0.55mm / 0.6mm |
| Thickness of Guiding Rail |
Gualvanized Steel,thickness: 2mm |
| Thickness of Panel |
40mm / 50mm |
| Width of Panel |
430mm / 550mm |
| Density of Sandwiches |
48kg/m3 |
| Surface Treatment |
Power coating,thickness of coating:30um |
| Heat Preservation |
4.5W/m.h |
| Wind Resistance |
Beaufort scale 11, 28m/s |
| Noise Level: |
≤60db |
| Sound Insulation Level |
24 Db |
| Fire Retardation: |
Class A |
| Speed |
0.2-0.4m / s |
| Max Dimension |
12m * 8m |
| Sealing Performance |
EPDM rubber all round sealing : two side, top, bottom,between door panels |
| Steel cord |
Flexible ,3.8mm |
| Power Supply |
380V 50Hz / 220V 50Hz |
| Service Life |
10 years |
| Emergency Operation |
Manual Hoist Chain to open the door in case of power off |
| Balance System |
a. Balance the weight of door through the torsion spring
b. Easily manual operation: 140N to open
c. Spring brake device:Anti-broken device
d. Service Life:100 thousand open & close
e. Prolong the service life of the motor |
| Safety |
Airbag protection, door anti-fall device, wire rope anti-break protection device. |
| Optional Item |
Window,pedestrian door |
Installation method
Safety & Security Features
Mechanical Safety Devices
Spring break and cable safety systems ensure safe operation.
Vision Panels for Traffic Awareness
Enhances visibility of moving forklifts and vehicles.
Controlled Door Operation
Prevents accidents in busy cargo loading zones.
Operation & Control Options
Manual Operation for Secondary Access
Low-traffic doors can be operated manually.
Automatic Operation for Main Cargo Bays
Electric operation improves workflow efficiency.
Integration with Security & Access Control Systems
Restricts access to authorized personnel and vehicles.
Typical Applications in Airport Cargo Buildings
Inbound Cargo Reception
Supports efficient unloading from trucks and containers.
Sorting & Storage Areas
Separates cargo by destination and handling requirements.
Outbound Shipping & Aircraft Loading Zones
Facilitates rapid transfer to aircraft or delivery trucks.
Maintenance & Equipment Storage Sections
Provides secure access for forklifts, pallets, and support equipment.
Customization Options
Door Size & Track Layout
Tailored to cargo bay dimensions and building structure.
Windows, Pass Doors & Accessories
Enhances visibility and personnel movement.
Surface Finish & Color Options
Supports facility branding and zone identification.
FAQ – Airport Cargo Buildings
Can sectional overhead doors handle frequent cargo operations?
Yes, designed for high-frequency industrial use with minimal downtime.
Are insulated doors necessary for airport cargo buildings?
Insulation is recommended for temperature-sensitive or perishable cargo areas.
Is automatic operation recommended?
Yes, automatic doors improve efficiency in main cargo bays.
Get a Door Solution for Airport Cargo Buildings
Project Consultation & Technical Support
Professional guidance for layout, selection, and integration.
Bulk Supply & OEM Solutions Available
Suitable for airport cargo hubs, logistics providers, and large-scale projects.
